Guilin Feiyu Electronic Technology Co., Ltd
Guilin Feiyu Electronic Technology Co., Ltd http://www.feiyu-tech.com [email protected]
Page 22
Connection ID number
Firmware of Panda
Ⅱ V1.2 or above version increased the ID number matching
function . Users can set the ID number of the Panda
Ⅱ by oneself , only when enter the correct ID
number on the GCS ,it can establish connection with Panda
Ⅱ .This function can effectively avoid the
problem which interference the control of the Padan2 because using the data radio in the same
frequency .
Version below Panda
Ⅱ Firmware V1.2 or other products which don’t need to set the ID
number (such as : FY-DOS, FY- 41AP),Please enter “00000” in the ID setting dialog box.
Setting ID number
The default ID number is ―00000‖. Users can enter any number between 00000~65535.For
example, we can reset the ID number as ―01234‖.When doing the ID number matching operation ，you
can only connect the UART port of the Panda
Ⅱ module to the computer via the USB cable . Or you
can doing the ID number matching operation under option 1 and option 2 .
But you have to ensure that install the jumper to P1 ,P2 when power on to execute the bounding
operation .
Install the jumper to P1,P2 port ,then power on to Panda
Ⅱ.
