Page 38
1) Click on
to start auto landing, first the aircraft will fly to circling point ―C‖.
2) When it reaches point ―C‖, it's will auto circling around point ―C‖, and gradually decline to 50
meters.
3) The aircraft will continuous to decline the altitude to proper position , according to the distance of
the plane to the "landing end point" and then at the right time to cut into A-B route .
4) Enter the A- B air line and control the altitude as far as possible to make the aircraft landed at point‖
B‖, and at the right time to close the throttle, end whole Auto Landing.
Note: Automatic landing need to have a range of open space ,suitable for small and light throwing
UAV. Maybe it is possible to damage the plane ,please used with caution.
( 2
） PARACHUTE
Auto parachute landing and landing air route setting is similar to the describe of the―LINEAR‖,the
difference is hovering down to the open parachute altitude then flight to the point ―B‖, automatically
shut off the throttle (Open the brake function of the ESC)
，then control the servo which use for
opening parachute , open the parachute.
12.9 Auto take photo setting and using method
Pl ease according to the―Camera installation‖instructions to do the Camera transformation in order to
enable the PandaⅡ to control. You can click on ― ‖ button to have a testing .It will take a
photo, when you click on it. Autopilot can take photos automatically according to the setting distance
or time interval. You can through click on button to choose use which one. After that you
can through ―Param1‖---
to set photo taken time or distance.
You can click on the to cancel the auto take photo function during the flight.
Auto Take Photo Waypoint setting
(Enter the serial number of waypoint.)
Starting waypoint: during the path navigation mode , auto take photo will be trigger at this waypoint
Ending waypoint: during the path navigation mode, auto take photo will be close automatically at
this waypoint.
The photo point will be mark with a small yellow flags on the map .
Note:
when the starting point and the ending point set as ―0‖,it means that disable the function of auto
taking photo waypoint
