Page 4
15. The GCS software includes electronic map formatting. By using the electronic map, aircraft route
and tasks can be modified in real-time via your GCS computer.
16. Real time display on the GCS includes flight parameters such as main pack voltage, mAh
consumed, Amp draw, GPS satellite strength and temperature of the autopilot unit.
17. All flight parameters are downloaded automatically by the GCS for instant playback.
18. IMPORTANT: GCS Function

When using the Data Radio to control the aircraft, the controlling signals from the RC
Receiver is directly sent to the Remote Adapter and converted to digital signals. The Data
Radio will then upload the commands to your aircraft via the data radio.

The GCS is only used to monitor telemetry and flight status of the aircraft. Transmission of
commands is minimal. i.e. the aircraft is mainly controlled by your RC Transmitter. The
autopilot still can realize most of the functions (for example, air route setting, RTH, circling)
without the GCS.
19. Support the firmware update, can update by yourself.
3. Technical parameters
Table 1.1: Unless specified, values are at operating temperature of 25 ℃.
Component
Min
Value Standar
d Value Max
Value
Units Remark
Main Supply Voltage 6.5 26 Volt
Main Supply Current 60 mA
At 5V supply
voltage
Altitude Measurement Range -500 6000 Meter
GPS Ground Speed
Measurement Range
0 350
Meter/Se
c
GPS Horizontal Navigation
accuracy
2.5 Meter Repeat Precision
Barometric Pressure Altitude
accuracy
2 Meter Repeat Precision
Waypoints setting 98
98 point
programmable
Rudder Servo 3 Channel
Throttle Channel 1 Channel
Servo Output Frequency 1 µS
Updated Servo Frequency 50 Hz
Flight status PID Control Rate 100 Hz
Navigation Control PID Rate 10 HZ
Data Telemetry‘s Track
1 Hz Maximum 10Hz
