Throttle
Warning: It is recommended that you remove your prop or disable your motor while
performing these setup procedure.
Pleases refer to the throttle output at the servo display as shown to the right. With your
throttle at the lowest setting the number should read 1000 . As your throttle up this number
should get larger. If instead the number reads 2000 and gets smaller as you increase the throttle
please select
“THR REV”
Rudder
(check in "Auto Balance Mode" )
CLOCKWISE rotate your plane , the rudder should move to the Left.
COUNTER CLOCKWISE rotation ,the rudder should move to the Right
If the servo movement is incorrect, you need to reverse the automated servo movement
please select
“RUD REV”.
Turn left
Rudder moves to the right
Turn right
Rudder moves to the left
