2*5P RC receiver connecting wires, use for
connect the RC receiver and Remote Adaptor,
the wires is arranged by the colors.
Yellow
——AIL；
White (bundled with red & black)
——ELE；
Orange
——THR； Green——RUD；
White
——CH5； Red——CH6；
Blue
——CH7； Brown——CH8
The wire connection about Remote Adaptor
and FY-602 Data radio.
The wire connection about Remote Adaptor
and USB data cable.
Attention:
You must use the 4P crosswire like
picture left shows, when you connect the USB
data cable and FY-602 data radio.
