Page 41
Considerations for Data Radio setting
1) Only in the same channel , the date radio can communicate with each other.
2) Because the Data Radio via USB-TTL data cable to power on the Data Radio will
immediately into work state when it power on, so the antenna should be installed before the USB-TTL
data cable connected to the computer, in order to avoid Data Radio frequency power amplifier circuit
part overheat and burn out
3) When you select the Data Radio setting ,the connection port of the GCS will close
auto
matically , if you want to use the GCS software again ,please click the ―connect ‖ button for
reconnection after finish the data radio setting .
12.11 Read POS data
PandaⅡ has already built-in POS information record module, and in the POS information record
module has 4M storage space, will automatically record photo-taken Pos information (if there is no
storage space already, but you still need to record, will through cover the first generate file to record
the new file). You can through the Data Radio directly connection to FY-PandaⅡ-POS information
read software to read the photo-taken Pos information (only after GPS positioning success that will be
generated the information file). In order to faster to get POS data ,you can use USB-TTL data cable
connected the Panda
Ⅱ autopilot to the computer USB port. .Open the GCS 5.1 and make Serial port
connection success . Select ―Menu---Read Pos Data‖ ,it will pop-up the ―POS INFORMATION
READ ‖ dialog box .(If you are using the Panda Ⅱ V1.2 firmware or above, you can only read POS
information via FYGCS 5.1 )
