Page 16
9.5 Airspeed Sensor module installation
The airspeed sensor need to pull ahead the front of the pneumatic opening and in the line with
the direction of flight. You can install the Airspeed sensor to the wing or in the front of the nose, do not
block the front of the air inlet , we can use the glue to fix the airspeed sensor.
Note: Make sure that after installation, the fuselage in flight airflow can not interfere with
air intakes.
9.6 Camera installation
The P1 port of the autopilot module output a camera shutter triggered signals, this signal is TTL
level(0-3V),but you need to do the camera transformation, open the camera and release the Camera
Remote Cord. The picture below show the transformation of Canon S100V.
