A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
SPECIFICATIONS 1
MODEL PM-1102X PM-1613/1623 PM-1613W/1623W
Number of detectors 1 1/2 1/2
Detector type GeX InGaAs InGaAs
Detector size (mm) 2 1 3
Wavelength range (nm) 750 to 1700 800 to 1700 800 to 1700
Power range (dBm) 20 to –75 2 9 to –80 3 8 to –70 3
Uncertainty (%) ±5 4 ±5 5 ±5 5
(10 dBm to –35 dBm) (0 dBm to –55 dBm) (0 dBm to –50 dBm)
Linearity 6 (dB) ±0.015 ±0.015 ±0.015
(0 dBm to –35 dBm) (0 dBm to –55 dBm) (0 dBm to –50 dBm)
Noise (peak-to-peak) 7 (pW) — 3 20
Power resolution 5 (dB) 0.001 (20 dBm to –35 dBm) 0.001 (9 dBm to –40 dBm) 0.001 (8 dBm to –40 dBm)
Wavelength resolution (nm) 1 0.01 0.01
Stabilization time (ms)
automatic range 12 (9 dBm to –80 dBm) 6 (8 dBm to –70 dBm)
automatic range 3 (9 dBm to –49 dBm) 3 (8 dBm to –49 dBm)
fixed range (1 to 4) 1 1
Sampling rate (sample/s/channel)
fast acquisition mode up to 4096 up to 4096
continuous measurement mode up to 40 up to 256 up to 256
Fiber type (μm) 5/125 to 62.5/125 5/125 to 62.5/125 5/125 to 62.5/125
Analog output
bandwidth 8 (Hz) (ranges 1 to 6) N/A 700 k; 700 k; 30 k; 30 k; 50 k; 7.5 k; 5 k; 7 k;
150; 150 (typical) 1 k; 1 k (typical)
output voltage (V) between 0 and 2.15 (typical) between 0 and 2.15 (typical)
output impedance ( Ω) 640 (typical) 640 (typical)
External trigger input voltage (V) N/A 0 to 5 (TTL) 0 to 5 (TTL)
General Specifications
Size (H x W x D) 11.7 cm x 22.2 cm x 33.3 cm (4 5 /
8
in x 8 3 /
4
in x 13 1 /
8
in)
Weight 2.0 kg (4.5 lb) 2.8 kg (6.2 lb) 2.8 kg (6.2 lb)
Temperature operating 0 °C to 40 °C (32 °F to 104 °F) 0 °C to 40 °C (32 °F to 104 °F) 0 °C to 40 °C (32 °F to 104 °F)
storage –40 °C to 70 °C (–40 °F to 158 °F) –35 °C to 70 °C (–31 °F to 158 °F) –35 °C to 70 °C (–31 °F to 158 °F)
Relative humidity 0 % to 80 % non-condensing 0 % to 80 % non-condensing 0 % to 80 % non-condensing
Notes
1. At 1310 nm (unless otherwise specified) with an FC/non-angled connector
and a warmup time of 20 minutes (30 minutes for PM-16X3W), followed by
an offset nulling.
2. From 0 °C to 30 °C.
3. From 18 °C to 32 °C.
4. At 23 °C ± 1 °C with an FOA-322 connector adapter, between 1000 nm
and 1650 nm. Add 1 % to uncertainty below 1000 nm and 3 % over 1650 nm.
5. At 23 °C ± 1 °C with an FOA-322 connector adapter, between 1000 nm
and 1640 nm. Add 1 % to uncertainty below 1000 nm and 6 % over 1640 nm.
6. Averaged measurement at constant temperature in 0 °C to 40 °C range.
7. Averaging time 0.25 s, observation time 50 s at 23 °C ± 1 °C, from 1200 nm
to 1640 nm.
8. Bandwidth corresponds to each electrical scale from the lowest to the highest gain.
9. Measured in 0 °C to 40 °C range.
