Front panel – EXFO PM-1100 Optical Power Meter User Manual
Page 12
Introducing the PM-1100 Optical Power Meter
2
PM-1100
Front Panel
Front Panel
Note: Your Optical Power Meter may slightly differ from the illustration.
Measurement units
control
Setup menu access
Program menu access
Recall menu access
Wavelength control
Relative mode access
New reference
Averaging mode
Offset nulling
Store menu access
Display
Arrow buttons for
menu navigation and
parameter setting
On/off button
Detector port
