1 - 10 LCD Panel Open - Model C Series

Quick Start Guide

1

LCD Panel Open - Model C Series

Figure 1 - 5

LCD Panel Open

Model C Series

1. Built-In 2.0M FHD

PC Camera

2. PC Camera LED

3. Built-In Array

Microphone

4. LCD

5. Speakers

6. Power Button

7. LED Status

Indicators

8. Illuminated

Keyboard

9. Touchpad and

Buttons

10. Fingerprint Reader

Module

4

1

9

7

8

5

6

2

3

3

5

10

Note that the Touchpad and
Buttons has a valid operational
area indicated within the dotted
lines above. See

“Clickpad/

Touchpad Sensitivity (Models
A, C & D)” on page 2 - 12

.
