LCD Panel Open - Models A & D 1 - 7
1
LCD Panel Open - Models A & D
Figure 1 - 2
LCD Panel Open
Models A & D
1. Built-In 2.0M FHD
PC Camera
2. PC Camera LED
3. Built-In
Microphone
4. LCD
5. Speakers
6. LED Status
Indicators
7. Power Button
8. Illuminated
Keyboard
9. Clickpad and
Buttons
10. Fingerprint Reader
Module
4
1
10
8
9
6
7
2
3
5
5
Note that the Clickpad and
Buttons has a valid operation-
al area indicated within the
dotted lines above. See
“Click-
pad/Touchpad Sensitivity
(Models A, C & D)” on page 2
- 12
.
