Page 38
Reserved
Mandatory EEPROM
On-Chip RAM
Extended Memory
(Configurable as:
Extended RAM
or
Non-volatile memory)
On-Chip ROM
0x0000 to 0x3FFF
0x4000 to 0xE7FF
0xE800 to 0xEFFF
0xF000 to 0xF7FF
0xF800 to 0xFFFF
2 KB
2 KB
2 KB
42 KB
16 KB
Figure 6. Memory Map for Series 5000 and 6000 Devices
Chips without Off-Chip Memory
On-chip memory on the Neuron 3120 Chips, the 3120 Smart Transceiver, and PL
3170 Smart Transceiver consists of ROM, RAM, and EEPROM. None of these
devices support off-chip memory. Figure 7 summarizes the memory maps.
28
Neuron Architecture for Neuron Assembly Programming
