XOR (Exclusive Or)
The XOR instruction performs a logical exclusive OR (XOR) for two numbers.
The OR instruction uses one of two addressing modes:
• In implicit addressing mode, the XOR instruction retrieves both TOS and
NEXT from the data stack and performs a bitwise logical XOR for them.
TOS and NEXT are consumed, and the result is placed in TOS. The
operation clears the Carry flag.
• In immediate addressing mode, the XOR instruction performs a bitwise
logical XOR for a specified one-byte constant number with the value of
TOS, and the result is placed in TOS. The value of number must resolve
at link time to a value in the range -128 to +127. The operation clears the
Carry flag.
The XOR instruction applies to Series 3100, 5000, and 6000 devices.
Syntax:
In implicit addressing mode, the XOR instruction requires no operands:
XOR
In immediate addressing mode, the XOR instruction requires one operand:
XOR #number
The number sign or hash (#) is required to specify the immediate value.
Table 58 describes the attributes of the XOR instruction.
Table 58. XOR Instruction
Instruction Hexadecimal
Opcode
Instruction
Size (Bytes)
CPU Cycles
Required
Affect on
Carry Flag
XOR 53 1 4 Cleared
XOR #number 5B 2 3 Cleared
Example:
The following example performs the operation (2 XOR 3) XOR 4.
pushs #2 ; (2, -, -)
pushs #3 ; (3, 2, -)
xor ; (1, -, -)
xor #4 ; (5, -, -)
The value of TOS after the first XOR instruction is 1 because 2 XOR 3 = 1. The
XOR #4 instruction performs a logical XOR of 4 with TOS (4 XOR 1), so that TOS
then contains 5.
