YSI 6200 DAS USER Manual
YSI/Massachusetts 508.748.0366, Fax 508.748.2543 Page 1-1
Section 1
Introduction
1.1 Description
The 6200 Data Acquisition System (6200 DAS) with EcoWatch DCP
ä
is an integrated hardware
and software package specifically designed to be a powerful, yet easy to configure, multiparameter
water quality and meteorological data collection platform with a graphical user interface.
Information can be collected real-time or periodically from solid state memory. Combined with
YSI 6-series sondes and/or a variety of meteorological sensors, this system is intended for use in
research, assessment and regulatory compliance applications.
Battery
(charged Solar or AC)
6200
Data Collection Platform
6-Series Sonde
Radio Transceiver
Radio
Base Station
Computer with
EcoWatch DCP
Wind Speed/Direction
Relative Humidity
Air Temperature
Solar
Radiation
Rain accumulation
Rain rate
Water Temperature
Conductivity
Dissolved Oxygen
pH
ORP
Depth/Level
and more...
Radio
Antenna
Barometer
Figure 1.1 6200 DAS, Example Configuration
The system can be configured many ways, using a variety of sensors, communication modes and
power options. The sensors provide signals for both water quality and meteorological
measurement parameters. The meteorological sensors include wind speed and direction, relative
humidity, barometric pressure, rainfall rate and accumulation, air temperature and solar radiation.
