YSI 6200 DAS USER Manual
YSI/Massachusetts 508.748.0366, Fax 508.748.2543 Page A-5
6213/6219 MET Sensor Suite
Description...
The MET sensor suite provides instantaneous measurement of wind speed, wind direction, relative
humidity and air temperature. It is designed as one multi-sensor unit with a single interface cable
that has strain relief at the sensor. The cable terminates in a 17 pin MS style connector. Two
versions are available, P/N 6213 - 15 ft (4.6 m) and P/N 6219 - 45 ft (13.7 m).
Features...
Extremely rugged
Easy installation, maintenance and replacement
Wind monitor has helicoid propeller with a wind survival of 220 mph (100 m/s)
Relative humidity sensor uses cellulose-strain gauge technology
Air temperature sensor is the YSI 44018 thermilinear bead thermistor
Specifications...
Physical
Height overall
20 in [51 cm]
Length overall 22 in [56 cm], includes vane and propeller
Propeller diameter 7.1 in [18 cm]
Weight 2.2 lbs [1 kg]
Wind Speed Sensor (WS) Wind Direction Sensor (WD)
Range 0-134 mph [60 m/s] 360
°
mechanical, 355
°
electrical
Survival 220 mph [100 m/s] 220 mph [100 m/s]
Threshold 2.2 mph [1.0 m/s] 2.2 mph [1.0 m/s]
Delay distance n/a 4.3 ft [1.3 m]
Temperature range -40
°
C to +40
°
C -40
°
C to +40
°
C
Power draw virtually none virtually none
Signal output sine wave, 90 Hz / 8.8 m/s analog VDC from precision low-torque
conductive plastic potentiometer
Relative Humidity Sensor (RH)
Accuracy
±
4%
Range 1 - 100%
Temperature range -40
°
C to 125
°
C
Air Temperature Sensor (AT)
Accuracy
±
0.3
°
C
Temperature range -40
°
C to 125
°
C
Warranty
1 year
