YSI 6200 DAS USER Manual
YSI/Massachusetts 508.748.0366, Fax 508.748.2543 Page 2-8
You should now open the EcoWatch DCP program. If you have not installed it yet refer to
Section 2.2, Installing EcoWatch DCP. Click on the Comm top line menu, then Settings…
Verify that the settings match the table.
Baud 9600
Data 8 bits
Parity None
Protocol Kermit
Handshaking XonXoff
Once complete with this window click on OK.
Now return to top line menu and click on Comm, then choose Sonde from the submenu. Select
your COM port and press OK. You will now see a window labeled Sonde – COM1.
The # sign should appear (see below). Type in “menu”. When you press Enter, you will enter
the main sonde menu. It will appear similar to the screen below. Any difference is related to the
model of sonde you are using.
If you are unable to establish interaction with the sonde, make sure that the cable is properly
connected, power is applied (e.g., 6038 Power Supply or other 12 VDC source), and that the
COM port settings are set correctly. If you were unsure of your COM port number, reassign
another port number and repeat the steps above.
