O PERATORS MANUAL FOR THE LH 85 S PRAY C ONTROLLER S YSTEM
LH A GRO 6.3
TEST OUTPUT
Each individual output can be tested here.
Highlight an output to be tested using the ARROW UP and DOWN keys then
press the ENTER key to change the status of the selected output:
Output Description
Liq valve PWM Press the ENTER key and encode a value from 0 to 100
(e.g. 50) the regulation valve will be sent a signal
corresponding to the encoded percentile value (e.g. 50%)
duty cycle when the "Liq valve enable" is set to "On".
Liq valve enable Press the ENTER key and the valve is sent the above
encoded duty cycle percent (status = "On").
Press the ENTER key once more and the valve will shut
(status = "Off").
Liq valve DIR This changes the direction of the main valve during test.
When "On" the valve will run in the direction for opening.
When "Off" the valve will run in the direction for shutting.
Agitation Out Press the ENTER key and tank agitation will start
(status = "On").
Press the ENTER key once more and agitation will stop
(status = "Off").
Master Valve Out Press the ENTER key and the main valve will open
(status = "On").
Press the ENTER key once more and the main valve will
close (status = "Off").
Fill Valve Out Press the ENTER key and the fill valve will open
(status = "On").
Press the ENTER key once more and the fill valve will close
(status = "Off").
