O PERATION O PERATORS MANUAL FOR THE LH 85 S PRAY C ONTROLLER
3.2 LH A GRO
OPERATION
All settings should be encoded/checked before any spray work commences.
Please refer to the SETTINGS section of this manual for a description of the
available settings.
USER SELECTABLE SPRAY RELATED INFORMATION
Symbol Description
Working pressure: The current working pressure shown as bar.
Flow rate: The present flow rate shown in litres per
hour.
Sprayed volume: The amount sprayed since the task was
started or since the counter was reset.
Volume left: The amount remaining for the present field
or task.
Density: The density of the liquid being used.
USER SELECTABLE WORK RELATED INFORMATION
Symbol Description
Forward speed: The present forward speed shown as
kilometres per hour.
Working width: The present working width shown as
metres.
Area covered: The total area covered shown as hectares
with 2 decimals since the task was started
or since the counter was reset.
Area is only measured when the sprayer is
in work.
Area left: The area that can be covered with the
current tank content.
This calculated figure is based on the
present volume in the tank, the actual
application rate and the current working
width.
Work efficiency: The present work efficiency shown as
hectares per hour.
This calculated value is based on the actual
forward speed and the present working
width.
