O PERATORS MANUAL FOR THE LH 85 S PRAY C ONTROLLER G ENERAL O PERATION
LH A GRO 2.7
JOB KEY (POS. A4)
Key Description
The JOB key is used for the task function. A description of the task
function can be seen on page 5.1.
ESCAPE KEY (POS. A5)
Key Description
The ESCAPE key is used to return to the previous menu without
saving any alterations.
ARROW KEYS (POS. A6, A8, A9, A10)
Key Description
The arrow keys are used to select and alter an encodement.
When encoding a value the arrow keys are used to select and
adjust the digit that needs changing.
Each digit can be set from 0 to 9 with the ARROW UP/DOWN keys.
The ARROW RIGHT/LEFT keys are used to select the digit to be
altered.
ENTER KEY (POS. A7)
Key Description
The enter key is used to accept settings and to return to the
previous screen.
CLEAR KEY (POS. 11)
Key Description
The clear key is used to reset settings/counters and to accept
warnings.
FUNCTION KEY 1 (POS. A12)
Key Description
Key 1
Pressing this key during operation pages through and selects the
user selectable work related information to be shown on the display.
A description of the work related information that can be displayed
can be seen on page 3.2.
C
Job
Esc
