O PERATORS MANUAL FOR THE LH 85 S PRAY C ONTROLLER O PERATION
LH A GRO 3.5
GO TO MANUAL
Using this function it is possible to change from automatic rate control to manual
rate control and back to automatic rate control again.
The function of the boost keys (pos. A13 & A14) changes to manual
increase/decrease when manual rate control is selected and the rate can be
altered using these keys.
• Pressing the + key increases the rate.
• Pressing the – key decreases the rate.
To return to automatic rate control again simply press the SETUP key and select
"Go to automatic"
SPEED SOURCE
It is possible to change the sensor, from which the forward speed signal is
received and used for regulation, during operation by using this function.
This function can be used when, e.g. different wheels are used on the implement.
A description of the available forward speed inputs can be seen in the following:
Symbol Description
Radar Pressing this key selects a signal from a
radar sensor.
Tractor wheel Pressing this key selects a signal from a
sensor fitted to the tractor.
Implement wheel 1 Pressing this key selects a signal from a
sensor fitted to the implement.
Pressing this key will show the next page and display the
following
Implement wheel 2 Pressing this key selects a signal from a
sensor fitted to the implement.
Implement wheel 3 Pressing this key selects a signal from a
sensor fitted to the implement
Simulated speed Pressing this key selects simulated forward
speed. When simulated speed has been
selected function keys 2 & 3 (pos. A13 &
A14) will allow the speed to be increased or
decreased.
The speed to be simulated is encoded in the
"Machine setup" menu under "Speed
source" (page 4.8).
Pressing this key will show the first page
For correct operation the speed signal sources to be used must be
calibrated accurately. The procedure for forward speed calibration can be
seen on page 4.5.
