G ENERAL O PERATION O PERATORS MANUAL FOR THE LH 85 S PRAY C ONTROLLER
2.6 LH A GRO
Boost or manual +/- (pos. 5):
The function of these keys may change depending on whether automatic or
manual rate control is selected in the "Fast setup" menu. See page 3.4
Increase or decrease the required application rate in steps using the function keys
(A13 & A14). See page 2.8.
The size of the steps (percent of current rate) is encoded under MACHINE SETUP
under "Boost" (see page 4.11).
When manual rate control has been selected from the "Fast setup" menu the
function of the keys changes to manual rate increase (+) and manual rate
decrease (-).
User selectable work information (pos. 6):
It is possible to select which work related information is displayed by pressing
function key 1 (A12).
A description of the work related information that can be displayed can be seen on
page 3.2.
User selectable spray information (pos. 7):
It is possible to select which spray related information is displayed by pressing
function key 4 (A15).
A description of the spray related information that can be displayed can be seen
on page 3.2.
SETUP KEY (POS. A2)
Key Description
The SETUP key is used to enter the setup menus.
If the main on/off switch (B6) is in the on position the "Fast setup"
menu is displayed (see page 3.4).
If the main on/off switch (B6) is in the off position the main setup
menu is shown. A description of the available settings can be seen
in the "Encode" chapter of this operators manual.
INFO KEY (POS. A3)
Key Description
Pressing the INFO key displays the following information (use the
up & down arrow keys (A6 & A10) to highlight and the ENTER key
(A7) to select. A detailed description of each function can be seen
on page 3.3:
• Controller • Counters
• Export/Import
• Diagnostics • Alarm log • Active alarms
Info
Setup
