S YSTEM O PERATORS MANUAL FOR THE LH 85 S PRAY C ONTROLLER
6.2 LH A GRO
DIAGNOSTICS
TEST INPUT
The "Test input" menu should be used if a sensor is suspected to be faulty.
For each input description there is, on the right-hand side of the display, a counter
that registers the number of times that the input in question has been activated
(this counter is reset each time "Test input" is exited or by pressing the C key).
The different inputs can be paged through by pressing the ARROW UP and
DOWN keys (there are 4 input pages).
The different input descriptions relate to the following:
Input Description
Wheel Forward speed signal from the speed sensor fitted to the tractor
(via the DIN/ISO socket in the tractor cab).
Radar Forward speed signal from the radar fitted to the tractor
(via the DIN/ISO socket in the tractor cab).
Impl. Wheel Forward speed signal from a speed sensor fitted on the sprayer
Flow 1 Signal from a flow meter fitted on the sprayer.
Pres. Sensor The current measured from a pressure sensor fitted on the
sprayer in mA.
Master In Current master switch status (HI or LO).
Press the ARROW DOWN key to see the next inputs:
Section 1 – 5 Current boom section status for boom sections 1 to 5 (HI or LO).
Press the ARROW DOWN key to see the next inputs:
Section 6 – 9 Current boom section status for boom sections 6 to 9 (HI or LO).
Press the ARROW DOWN key to see the next inputs:
Flow 2 Signal from a fill flow meter fitted on the sprayer.
Tank Signal from the tank level sensor fitted to the sprayer tank.
Wind speed Signal from an anemometer.
