S

ETTINGS

O

PERATORS MANUAL FOR THE

LH

85

S

PRAY

C

ONTROLLER

4.18

LH

A

GRO

Key

Description

Key

Description

MIN FLOW key

FLOW INPUT key

MAX FLOW key

CALIBRATE key

1. From "OEM setup" select "Sensors".
2. From "Sensors" select "Calibration".
3. From "Calibration" select "Flow meter".
4. Select the flow meter for which the minimum and maximum flow rates are to

be encoded by pressing the FLOW INPUT key. The text directly above the
function keys shows which flow meter is being encoded.

5. Press the MIN FLOW key.
6. Encode the minimum flow rate of the flow meter in litres per minute.
7. Press the ENTER key.
8. Press the MAX FLOW key.
9. Encode the maximum flow rate of the flow meter in litres per minute.
10. Press the ENTER key.


If the number of pulses per litre for the flow meter is not known or to make sure
that the value is correct an automatic calibration function is available. A description
of how to use the automatic calibration follows:
Automatic flow meter calibration:

1. From "OEM setup" select "Sensors".
2. From "Sensors" select "Calibration".
3. From "Calibration" select "Flow meter".
4. Select the flow meter for which the minimum and maximum flow rates are to

be encoded by pressing the FLOW INPUT key. The text directly above the
function keys shows which flow meter is being encoded.

5. Press the CALIBRATE key.
6. Press the ENTER key.
7. Press the START key and start spraying.
8. When minimum 100 litres has been sprayed stop spraying.
9. Press the STOP key and encode the actual amount sprayed.
10. Press the ENTER key and the flow meter is calibrated.
