TeeJet LH 85 - Manual (Page 21)

O PERATORS MANUAL FOR THE LH 85 S PRAY C ONTROLLER O PERATION
LH A GRO 3.3
Symbol Description
Distance covered: The distance covered shown as metres
since the task was started or since the
counter was reset.
Distance is only measured when the sprayer
is in work.
Distance left: The distance that can be covered with the
current tank content.
This calculated figure is based on the
present volume in the tank, the actual
application rate and the current working
width
Elapsed time: The time passed since the task was started
or since the counter was reset.
Time is only measured when the sprayer is
in work.
Wind speed: The current wind speed shown in metres
per second.
This function is only possible when the main
on/off switch is in the off position and the
forward speed = 0 and if the system is fitted
with an anemometer.
INFO MENU
Pressing the INFO key displays the following menu structure.
Each item in the menu is described in the following:
