O PERATORS MANUAL FOR THE LH 85 S PRAY C ONTROLLER G ENERAL O PERATION
LH A GRO 2.9
NAVIGATING THROUGH THE MENUS
The LH 85 Spray controller uses a menu based structure for most functions.
Navigation through the menus is simple and unified throughout the whole
programme.
SELECTING AN ITEM FROM A MENU AND ALTERING A VALUE
The procedure to select and alter a setting in the LH 85 Spray controller is simple
and requires very little practice.
The procedure to navigate, select and alter a setting is best illustrated with an
example, which follows:
Step Key Action
To alter the nozzle configuration for a programmable nozzle (P1).
1 Switch the main on/off switch (pos. B6) to the OFF position (down).
2 Press the SETUP key and the following is shown in the
display:
3 Press the ARROW DOWN key to move the cursor to
"Machine"
Setup
