S ETTINGS O PERATORS MANUAL FOR THE LH 85 S PRAY C ONTROLLER
4.8 LH A GRO
Manual speed sensor calibration:
If the number of pulses received per driven 100 metres is known then this can be
encoded directly thus:
Step Key Action
1 From the "Machine" setup menu select "Speed source".
2 From the "Speed source" menu select "Speed source".
3
Keys 3 & 4
Select the speed sensor to be calibrated by using function
keys 3 & 4 (pos. 5 & 6 in the above).
Use the page key (pos. 4 in the above) to view/select other
sensors.
4 Encode the number of pulses per 100 metres using the
ARROW keys.
5 Press the ENTER key and the forward speed sensor has
been calibrated.
SIMULATED SPEED
To use simulated forward speed in the LH 85 Spray controller do as follows:
Step Key Action
1 From the "Machine" setup menu select "Speed source".
2 From the "Speed source" menu select "Simulated speed".
3 Press the "Low" speed key and enter the lowest speed to
be simulated in kilometres per hour with 1 decimal.
4 Press the ENTER key.
5 Press the "High" speed key and encode the highest speed
to be simulated in kilometres per hour with 1 decimal.
