Typical reflow sprayer plumbing diagram – TeeJet TASC-6600 User Manual
Page 50
A-4
TASC-6000, 6300, 6600
98-05010
Rev. - 1
To Spray Booms
Boom
Valves
Two way
BYPASS ADJUST
VALVE
INJECTION PUMP ASSEMBLIES
Quick Fill
Port
CHEMICAL TANK ASSEMBLIES
MICRO - TANK
MICRO - TANK
Main Water/Carrier
Pump
Flow
Control
Valve
Inline
Filter
CALIBRATION VALVES
Calibration
Ports
INJECTION
MANIFOLD
Flow
Meter
Reflow line
TYPICAL REFLOW
SPRAYER
PLUMBING DIAGRAM
REFLOW BYPASS
VALVES
DO NOT REFLOW TO THE MAIN TANK
WHEN OPERATING AN INJECTION
SPRAYER!
MAIN WATER TANK
A.3 REFLOW PLUMBING DIAGRAM
