J4 specifications – Solvline Eddy DK User Manual
Page 24
Eddy DK Programmer Guide
24
J4 Specifications
J4
Pin
Signal Name
Pin
Signal Name
1
PB12
2
PB13
3
PB30
4
PB31
5
PB0
5
PC22
7
PB1
8
PB16
9
PB2
10
PB17
11
PB3
12
PB18
13
BHDM
14
PB19
15
BHDP
16
PB20
17
A16
18
PB21
19
A17
20
A18
21
D8
22
D9
23
D10
24
D11
25
D12
26
D13
27
D14
28
D15
29
TWD
30
TCK
31
NANDOE
32 NAND_CLE / A22
33
NANDWE
34 NAND_ALE / A21
35
NC
36
NC
