9.3.2 Eddy DK v2.1 Specificatons
Classification Specification
NAND Flash 256MB, 8bit I/F
SD Card
Connector Push Type, Up to 16 GB
MMC / SD Card / MC supported
USB Connector
1 x Device
2 x HOST, Dual-Port
LCD Module 128 x 64 Dots Matrix Structure
KEY 4 x 4 Matrix
Battery Holder 3V Lithium Battery, 235 mAh
LED Power, Ready, 20 Programmable IO, Console & Serial TxD, RxD
I2C Interface 16bit I2C BUS GPIO
SPI Interface 2 Kbit EEPROM
MCI Interface SD Card, MMC Socket
ADC Interface Temp / Light Sensor
Digital I/O 8 Port Input, 8 Port Output
Switch
- Serial or GPIO Select
- RS422/485 Select
- DIO : Common VCC or GND Select
- Programming
Jumper Switch Boot Mode Select, JTAG Select
Serial Port
2 x RS232 DB9 Male
2 x RS422/485 Terminal Block
(RS422 & RS485 Selected by S/W)
Console Port DB9 Male
LAN Port 2 x RJ45
ICE Port Used for Flash Programming
Reset Button Factory Default & Warm Boot
Input Power 9-48VDC
Dimensions 240 x 180 mm
