Eddy DK Programmer Guide
146
Classification
Specification
Eddy-S4M v2.1 Eddy-S4M v2.5
CE Class A,
FCC Class A,
RoHS
compliant
9.3.4 Eddy-S4M-DK v2.1 Specifcatons
Classification Specification
Serial Port
2 x RS232 DB9 Male
2 x RS422/485 5pin Terminal Block (S/W Selectable & with Auto toggle)
SD Card Connector
Push Type, Up to 16 GB
MMC / SD Card / MC supported
MCI Interface SD Card, MMC Socket
ADC Interface Light Sensor
USB Connector 1 x Device, 2 x HOST, Dual-Port
LAN Port RJ45 with transformer
Console Port DB9 Male
Switch
Power ON/Off switch
Serial RS422/485 Termination resistor configuration switch
Input switch for testing GPIO (Off : Low, ON : High)
LED RDY, Power, 34 Programmable IO, Console & Serial TxD, RxD LED
JTAG Port Used for downloading code and single-stepping through programs
Reset Button
Factory Default & Warm Boot
(If you posh more than 5, active Factory default)
JIG connection
socket
2 2x23pin socket, which connect JIG board to confirm problems
Expansion Header 2x22pin Header, used to test GPIO of Eddy-S4M
Input Power 5 VDC
Dimensions 160 x 120 mm
9.3.5 Eddy-S4M-JIG v2.1 Specifcatons
Classification Specification
USB Connector USB HOST
LAN Port RJ45
Reset Button Factory Default & Warm Boot
Expansion Header 2 2x23pin, used to connect most functions of S4M to externalS4M
Input Power 5 VDC
Dimensions 70 x 105 mm
