Eddy DK Programmer Guide
17
J2 Specifications
Connect USB cable to J1 while the jumper is connected to J2, so that applications can be compiled, linked, created, and uploaded to the Eddy-CPU module. (Please refer to
Programmer Guide for more information.)
J2
Pin
Signal Name
Pin
Signal Name
1
A15
2
A14
3
A13
4
A12
5
A11
5
A10
7
A9
8
A8
9
A7
10
A6
11
A5
12
A4
13
A3
14
A2
15
A1
16
A0
17
PC9
18
NWE
19
FPG
20
NRD
21
GND
22
3.3V
23
GND
24
3.3V
25
D7
26
D6
27
D5
28
D4
29
D3
30
D2
31
D1
32
D0
33
PC13
34
JTAGSEL
35
PC12
36
NC
