Eddy DK Programmer Guide
134
9.2 System recovery via USB
Even if the flash in the user area has been damaged, it does not affect system booting. But if the system
continuously reboots due to user program failure, or if the system is inaccessible as a result of wrong IP setting, you
have to change the system to factory default status. You can reload firmware via USB to change the system to
default status.
(Note: USB System recovery may be affected by the characteristics of your PC ' s USB port.)
9.2.1 System recovery preparation via USB
Please refer to the follows because the installation procedures of Eddy-CPU v2.1 and Eddy-CPU v2.5 differ.
Eddy-S4M v2.1 is compatible with Eddy-CPU v2.1 and Eddy-S4M v2.5 is compatible with Eddy-CPU v2.5.
Eddy-CPU/mp v2.5 is compatible with Eddy-CPU v2.5
Eddy-CPU v2.1 or Eddy-S4M v2.1
Copy Eddy-CPU_v21_USB_Recovery.zip file to any folder (e.g. C:\SystemBase\USB_recovery) from
SDK\Windows\USB_recovery folder in Eddy DK CD.
Double-click ‚AT91-ISP.exe‛ file and begin the
installation process of USB Tool program, then
click Next.
On the splash screen, click I Agree.
Browse to the following folder, then click
Next.
C:\ProgramFiles\ATMELCorporation\
AT91-ISP v1.12
