Eddy DK Programmer Guide
147
9.3.6 Eddy-WiFi v3.0 Specifcatons
Classification Specification
Standard 802.11b, 802.11g, 802.11n
Modulation
802.11b:CCK, DQPSK, DBPSK
802.11g:64 QAM, 16 QAM, QPSK, BPSK
802.11n:BPSK, QPSK, 16-QAM, 64-QAM
Frequency Band ISM band 2.4GHz ~ 2.4884GHz
Output Power
802.11b:16 dBm (11Mbps)
802.11g:14 dBm (54Mbps)
802.11n:14 dBm (20MHz BW,MCS7)
13 dBm (40MHz BW,MCS7)
RX sensitivity
802.11b:-84dBm@11MHz
802.11g:-73dbm@54MHz
802.11n:-71dBm(MCS 7_HT20)
-68dBm(MCS 15_HT20)
-68dBm(MCS 7_HT40)
-65dBm(MCS 15_HT40)
Security
WPA, WPA-PSK, WPA2, WPA2-PSK
, WEP 64bit & 128bit
, IEEE 802.11x, IEEE 802.11i
Working distance
60 - 120m, depending on surrounding
Environment
Data Rate
802.11b: 11, 5.5, 2, 1
802.11g: 54, 48, 36, 24, 18, 12, 9, 6
802.11n:
20 MHz BW: 130, 1117, 104, 78, 65, 58.5, 52, 39, 26, 19.5,
13, 6.5
40 MHz BW: 270, 243, 216, 162, 150, 135, 121.5, 108, 81, 54,
40.5,
27, 13.5 (unit: Mbps)
Antenna ANT 2.4Ghz 2DB, 1 x U.FL
Dimension 28.2 X 45.4 X 9.6 mm
Operating Temp -10 ~ 70°C
Operating Voltages 3.3V±5% I/O supply voltage
Weight 10g
Approvals KC, RoHS Compliant
