Eddy DK Programmer Guide

143

9.3 Product Specification

9.3.1

Eddy CPU v2.1 Specifications

Item

Classification

Specification

Eddy-CPU v2.1

Eddy-CPU v2.5

Hwrdware

CPU

ARM926EJ-S (210 MHz)

AT91SAM9G20 (400 MHz)

Memory

8MB Data Flash, 32 MB SDRAM

External I/F

19 Bit / 16 Bit Data Bus

Ethernet I/F

10/100 Base-T Auto MDI/MDIX

UARTs

4 Port, Support up to 921.6 Kbps
(1 : Full Signal, 2,3,4, : RxD, TxD, RTS, CTS only)

USB 2.0 FS

2 Host /1 Device Port, 2.0 FS (12Mbps)

ADC

4-Channel 10 Bit ADC

TWI(I2C)

Master, Multi-Master and Slave Mode

SPI

8- to 16-bit Programmable Data Length
Four External Peripheral Chip Selects

GPIO

Max. 56 Programmable I/O Pins

Power Input

3.3 V (200 mA Max)

Dimensions

25 x 48.5 x 6.2 mm

Weight

8.3 g

Network

Protocol

TCP, UDP, Telnet, ICMP, DHCP, TFTP, HTTP, SNMP 1&2, SSH, SSL

Ethernet

10/100Mbps MAC / PHY

Network
Connection

Static IP, DHCP

Software

O/S

Linux Kernel 2.6.21

Mgt Tools

SNMP, Web, PortView

Uploads

TFTP, FTP, Web

Dev Tools

LemonIDE & SDK

Environmental

Operating Temp

-40 ~ 85 ℃

Storage Temp

-60 ~ 150 ℃

Humidity

5 ~ 95% Non-Condensing

Approvals

CE Class A,
FCC Class A,
RoHS
compliant
