Eddy DK Programmer Guide
16
31
LED_Speed
J10_31
-
LAN connection speed
Speed
Pin State
LED Definition
10Base-T
H
OFF
100Base-TX
L
ON
32
LED_Link
J10_32
-
LAN connection status
Link/Activity
Pin State
LED Definition
No Link
H
OFF
Link
L
ON
Activity
Toggle
Blinking
33
LAN_RX-
J10_33
-
CPU 내부 Ethernet PHY(WAN)의 Physical receive or transmit signal (- differential)
34
LAN_RX+
J10_34
-
CPU 내부 Ethernet PHY(WAN)의 Physical receive or transmit signal (+ differential)
35
LAN_TX-
J10_35
-
Physical transmit of CPU Internal Ethernet PHY(WAN) or receive signal (- differential)
36
LAN_TX+
J10_36
-
Physical transmit of CPU Internal Ethernet PHY(WAN) or receive signal (+ differential)
