Page 62
EVS Series Emergency Voice System Installation Manual
4-40
LS10062-001-SK-E
4.8.2
Wiring the EVS-RVM
1. Refer to Figure 4-39 to properly connect the EVS-RVM to the FACPs SBUS.
Figure 4-39 SBUS Connections
2. See Section 4.9 to set SBUS addressing.
3. Connect the SBUS to the annunciator and EVS-RVM. See Figure 4-40.
Figure 4-40 SBUS Wiring for EVS-RVM
FACP
Supervised
Power Limited
EVS-RVM
From Previous
SBUS Device
Annunciator
EVS-RVM
