SilentKnight EVS User Manual
Page 34
EVS Series Emergency Voice System Installation Manual
4-12
LS10062-001-SK-E
6. Connect one end of the wiring harness (P/N 130398 supplied) to the EVS-VCM
and the other end to the EVS-SW24 as shown in Figure 4-13.
Figure 4-13 Wiring Harness Connection
7. Restore AC power.
8. Reconnect backup batteries.
Wiring Harness
