Page 27
EVS Device Installation
LS10062-001-SK-E
4-5
3. Using a Phillips head screw driver, remove the six screws that hold the dead front
panel in place. See Figure 4-4.
Figure 4-4 Cabinet Door and Dead Front Panel Removal
4. Using a 1/4” Hex drive, remove the six Hex nuts that hold the cabinet door in
place. See Figure 4-4.
Re-Attaching the Cabinet Door
To re-attach the cabinet door reverse the procedure in section 4.1.3.1.
4.2 Connecting AC Power and Batteries
Refer to the FACP’s installation manual for proper AC power connections.
EVS Series Model Number
FACP Installation Manual
5820XL-EVS
LS10061-001SK-E
Cabinet Door
Dead
Front Panel
Dead Front
Panel Screws
Cabinet Door
Hex Nuts
