Before you Begin Installation
LS10062-001-SK-E
3-3
3.3 SBUS Specifications
Refer to Section 4 of the FACP’s installation manual for SBUS wiring details.
3.4 Electrical Specifications
Table 3-1: EVS-50W AC Current Draw
Table 3-2: EVS-125W AC Current Draw
EVS-Series Model Number
FACP Installation Manual
5820XL-EVS
LS10061-001SK-E
Module
Voltage
Standby
Current
Alarm
Current
EVS-50W 25V
120V 60 Hz
350 mA
1100 mA
EVS-50W 70V
120V 60 Hz
350 mA
1200 mA
Module
Voltage
Standby
Current
Alarm
Current
EVS-125W 25V
120V 60 Hz
300 mA
2200 mA
