2 class b (style y), 3 class a (style z) – SilentKnight EVS User Manual
Page 52
EVS Series Emergency Voice System Installation Manual
4-30
LS10062-001-SK-E
4.6.4.2 Class B (Style Y)
Figure 4-28 illustrates how to wire speakers to the control panel using Class B (Style
Y) supervision.
Figure 4-28 Class B (Style Y) Speaker Configuration
4.6.4.3 Class A (Style Z)
Figure 4-29 illustrates how to wire speakers to the control panel using Class A (Style
Z) wiring.
Figure 4-29 Class A (Style Z) Speaker Configuration
15k
EOL
UL Listed
Supervised
Power Limited
Supervised
Power Limited
