EVS Series Emergency Voice System Installation Manual
4-38
LS10062-001-SK-E
4.8 Installing the EVS-RVM
The EVS-RVM Remote Voice Module is contained within the EVS-RCU Remote
Command Unit. It provides a supervised microphone for live communication and an
interface for the Emergency Voice System.
4.8.1
EVS-RVM Board Layout
The following is description of the EVS-RVM remote voice module components.
Note: The EVS-VCM and EVS-RVM circuit boards look similar, but they are not interchangeable. The
EVS-VCM is mounted in the 5820XL-EVS and the EVS-RVM is mounted in the EVS-RCU cabi-
net.
Figure 4-37 Back View of EVS-RVM
VBUS
Microphone
Connector
SBUS Address
DIPs
AUX
Dead Front Panel
SBUS
Audio
Input
AUX
Audio
Trigger
Mounting Holes
EVS-SW24
Connector
Not
Used
