SilentKnight EVS User Manual
Page 59
EVS Device Installation
LS10062-001-SK-E
4-37
2. Connect the audio expander cable harness (P/N 130426) from the connector
labeled “Audio Expander” on the EVS-50W/EVS-125W to the connector on the
EVS-CE4 as shown in Figure 4-36.
Figure 4-36 Audio Expander Wire Harness Connections
3. Wire audio circuits as shown in Section 4.5.4.
EVS-CE4
Connector
EVS-125W
Audio
Expander
