EVS Series Emergency Voice System Installation Manual
4-36
LS10062-001-SK-E
4.7 Installing the EVS-CE4
The EVS-CE4 adds four audio circuits to the EVS-50W or EVS-125W. The EVS-CE4
mounts inside the EVS-50W or EVS-125W cabinet
Follow these steps to install the EVS-CE4:
1. Using the four supplied screws mount the EVS-CE4 in the EVS-50W or EVS-
125W cabinet as shown in Figure 4-35.
Figure 4-35 Mounting the EVS-CE4
Mounting
Screws
Mounting
Screws
EVS-CE4
