151053-L8
1-1
Section 1
Introduction
The Model 5104 is a low-cost fire communicator that meets the requirements for NFPA 72, UL 864, MEA,
CSFM, and FM.
1.1
Feature
•
Six supervised fire zones, consisting of one Class A (Style D) and five Class B
(Style B) zones.
•
Current limited loop power output for the Class B zone inputs.
•
Ground fault detection.
•
Built-in piezo sounder for trouble and supervisory conditions.
•
Reset/Silence switch that performs the following:
1
Silences troubles and alarms.
2
Resets smoke detector power.
3
Resets accessory power.
•
Supervision of Reset/Silence switch. If the switch is depressed for 15 seconds or longer, an audible trouble
signal will occur. See section 3.4.3
•
24 hour battery backup from a 12 VDC, 7 Ah rechargeable battery.
•
Separate battery charging circuit that maximizes battery life.
•
Multiple reporting formats (SIA, SK 3/1, Sescoa 3/1, Contact ID, SK 4/2, Radionics BFSK).
•
Programmable relay output provides additional annunciation for either alarm or dialer-failed condition.
•
Three LEDs indicating AC power (green) status, Trouble Silenced (yellow), and Dialer Failed (yellow).
•
Four LEDs inside cabinet indicate short circuits and trouble conditions.
•
Easy, English-language programming using the 5230 Remote Annunciator.
•
Versatile two-number dialing feature for reporting to two different numbers.
•
Programmable dialing format (rotary or Touch Tone).
•
Two phone line monitoring and seizure circuits.
•
Transient Voltage protection on all inputs (AC, phone lines, accessory zones).
•
Automatic daily test.
•
EEPROM memory storage of all programmed information.
1.2
Accessory Devices
•
Model 5230 Remote Annunciator (optional). Used for system control, programming and troubleshooting.
•
Model 7860 modular cable with spade lugs for connection to Telco RJ31X plug (optional).
1.3
About This Manual
This manual is intended for those persons involved with the installation and maintenance of the 5104 Fire
Communicator. It is a comprehensive guide providing detailed instructions, and should be kept for reference. As
