APPENDIX

TECHNICAL DATA - Sizes 30 - 125 (Data applies to both Models UDBP and UDBS unless noted otherwise.)
Size

30

45

60

75

100

125

Input Heating Capacity

BTUH

30,000 45,000 60,000 75,000 105,000 120,000

kw/h

8.8

13.2

17.6

22.0

30.8

35.2

Thermal Efficiency (%)

82

82

82

82

83

83

Output Heating Capacity

A

BTUH

24,600 36,900 49,200 61,500 87,150

99,600

kw/h

7.2

10.8

14.4

18.0

25.6

29.2

Gas Connection (inches)

B

Natural

1/2

1/2

1/2

1/2

1/2

1/2

Propane

1/2

1/2

1/2

1/2

1/2

1/2

Vent Connection Size

C

(inches diameter)

4

4

4

4

4

4

Control Amps (24 volt)

1.0

1.0

1.0

1.0

1.0

1.0

Full Load Amps (with standard HP 115V motor)

3.7

3.7

7.1

7.1

13.0

13.0

Maximum Over Current Protection (115V)

D

15

15

15

15

30

30

Normal Power Consumption (watts @ full load, medium speed)

215

215

447

447

537

537

Minimum Discharge Air

Temperature Rise

See Paragraph 2.2

for sound data based

on blower speed.

°F

45

45

45

45

45

45

°C

25

25

25

25

25

25

Maximum Discharge Air

Temperature Rise

°F

75

75

75

75

75

75

°C

41.7

41.7

41.7

41.7

41.7

41.7

Maximum Air Volume

CFM

506

759

1012

1265

1793

2049

M

3

/minute

14.3

21.5

28.7

35.8

50.8

58.0

Minimum Air Volume

CFM

304

456

607

759

1076

1230

M

3

/minute

8.6

12.9

17.2

21.5

30.5

34.8

Discharge Air Opening Area

FT

2

0.1

0.1

1.3

1.3

2.0

2.0

M

2

0.1

0.1

0.1

0.1

0.2

0.2

Maximum Output Velocity

FPM

527

791

810

1012

892

1020

M/minute

159

239

239

299

267

305

Minimum Output Velocity

FPM

316

475

486

607

535

612

M/minute

96

143

143

179

160

183

Standard Blower Motor HP

1/6

1/6

1/3

1/3

3/4

3/4

Blower Size

inches

9 X 6

9 X 6

9 X 6

9 X 6

10 X 10 10 X 10

TECHNICAL DATA - Sizes 150 - 400 (Data applies to both Models UDBP and UDBS unless noted otherwise.)
Size

150

175

200

225

250

300

350

400

Input Heating Capacity

BTUH

150,000

175,000

200,000

225,000

250,000

300,000

350,000

400,000

kw/h

43.9

51.2

58.6

65.9

73.2

87.8

102.5

117.1

Thermal Efficiency (%)

83

83

83

83

83

83

83

82

Output Heating Capacity

A

BTUH

124,500

145,250

166,000

186,750

207,500

249,000

290,500

328,000

kw/h

36.4

42.5

48.6

54.7

60.8

72.9

85.1

96.0

Gas Connection (inches)

B

Natural

1/2

1/2

1/2

3/4

3/4

3/4

3/4

3/4

Propane

1/2

1/2

1/2

3/4

3/4

3/4

3/4

3/4

Vent Connection Size

C

(inches diameter)

5

5

5

5

5

6

6

6

Control Amps (24 volt)

1.0

1.0

1.0

1.0

1.0

1.0

1.0

1.0

Full Load Amps (w/std HP 115V motor)

5.9

9.6

10.5

12.7

12.7

17.7

27.3

27.3

Maximum Over Current Protection (115V)

D

15

20

25

30

30

40

60

60

Normal Power Consumption (watts)

230

415

485

675

675

1260

1635

1635

Minimum Discharge Air

Temperature Rise

See Paragraph

2.2 for sound

data based on

temperature

rise.

°F

45

45

45

45

45

45

45

50

°C

25

25

25

25

25

25

25

27.8

Maximum Discharge Air

Temperature Rise

°F

75

75

75

75

75

75

75

80

°C

41.7

41.7

41.7

41.7

41.7

41.7

41.7

44.4

Maximum Air Volume

CFM

2562

2989

3416

3843

4270

5123

5977

6185

M

3

/minute

72.5

84.6

96.7

108.8

120.9

145.1

169.2

175.1

Minimum Air Volume

CFM

1537

1793

2049

2306

2562

3074

3586

4100

M

3

/minute

43.5

50.8

58.0

65.3

72.5

87.0

101.5

116.1

Discharge Air Opening Area

Ft

2

2.6

2.6

2.6

3.5

3.5

4.8

4.8

4.8

M

2

0.2

0.2

0.2

0.3

0.3

0.5

0.5

0.5

Maximum Output Velocity

FPM

1001

1168

1334

1095

1217

1070

1248

1291

M/minute

305

356

407

334

371

326

380

393

Minimum Output Velocity

FPM

600

700

800

657

730

642

749

856

M/minute

183

213

244

200

223

196

228

261

Standard Open 115V Blower Motor HP

1/4

1/2

1/2

3/4

3/4

1-1/2

2

2

Blower Size

inches

12 x 12

12 x 12

12 x 12

15 x 11

15 x 11

15 x 15

15 x 15

15 x 15

A

CSA ratings for altitudes to 2000 ft.

B

Size shown is for gas connection to a single-stage gas valve, not supply line size.

C

Smaller and/or larger vent pipe diameters may be permissible; refer to the Venting Installation Manual for Power Vented Units.

D

MOPD = 2.25 x (largest motor (FLA) + smallest motor FLA. Answer is rounded to the nearest commercially available circuit breaker.
