72
 UDP Port Display the current UDP port.
 Time Out Display the current time out.
 Retries Display the current retry times.
 Action
: Delete the SNMPv1, 2 host entry.
4.2.7.9 SNMPv3 Notification Recipients
Configure SNMPv3 notification recipients on this page. The SNMPv1, 2 Notification Recipients screens in Figure
4-2-33 & Figure 4-2-34 appear.
Figure 4-2-33 SNMPv3 Notification Recipients Page Screenshot
The page includes the following fields:
Object Description

Server Address Indicates the SNMP trap destination address. It allows a valid IP address in
dotted decimal notation ('x.y.z.w'). It can also represent a legally valid IPv4
address. For example, '::192.1.2.34'.
 Notify Type Set the notify type in traps or informs.
 User Name Indicates the user string when send SNMP trap packet.
 UDP Port Indicates the SNMP trap destination port. SNMP Agent will send SNMP
message via this port, the port range is 1~65535.
 Time Out Indicates the SNMP trap inform timeout. The allowed range is 1 to 300.
 Retries Indicates the SNMP trap inform retry times. The allowed range is 1 to 255.
Buttons
