321
Figure 4-12-4 LLDP Port Status Page Screenshot
The page includes the following fields:
Object Description
 Port The switch port number of the logical port.
 State Display the current LLDP status
 Selected Optional
TLVs
Display the current selected optional TLVs
The VLAN Name TLV VLAN Selection and LLDP Port VLAN TLV Status screens in Figure 4-12-5 & Figure 4-12-6
appear.
Figure 4-12-5 VLAN Name TLV Selection Page Screenshot
