Page 294

294
Figure 4-10-4
MAC-based ACE Table Page Screenshot
The page includes the following fields:
Object
Description
ACL Name
Display the current ACL name
Sepuence
Display the current sequence
Action
Display the current action
Destination MAC Address
Display the current destination MAC address
Destination MAC Address
Mask
Display the current destination MAC address mask
Source MAC Address
Display the current source MAC address
Source MAC Address Mask
Display the current source MAC address mask
VLAN ID
Display the current VLAN ID
802.1p
Display the current 802.1p value
802.1p Mask
Display the current 802.1p mask
Ethertype
Display the current Ethernet type
Modify
Click
to edit MAC-based ACL parameter.
Click
to delete MAC-based ACL entry.
4.10.3 IPv4-based ACL
This page shows the ACL status by different ACL users. Each row describes the ACE that is defined. It is a conflict if a
specific ACE is not applied to the hardware due to hardware limitations. IPv4-based ACL screens in
Figure 4-10-5
&
