The page includes the following fields:
Object
Description
ACL Name
Display the current ACL name
Sepuence
Display the current sequence
Action
Display the current action
Protocol
Display the current protocol
Source IP Address
Display the current source IP address
Source IP Address
Wildcard Mask
Display the current source IP address wildcard mask
Destination IP
Address
Display the current destination IP address
Destination IP
Address Wildcard
Mask
Display the current destination IP address wildcard mask
Source Port Range
Display the current source port range
Destiantion Port
Range
Display the current destination port range
Flag Set
Display the current flag set
DSCP
Display the current DSCP
IP Precedence
Display the current IP precedence
ICMP Type
Display the current ICMP Type
ICMP Code
Display the current ICMP code
Modify
Click
to edit IPv4-based ACL parameter.
Click
to delete IPv4-based ACL entry.
4.10.5 IPv6-based ACL
This page shows the ACL status by different ACL users. Each row describes the ACE that is defined. It is a conflict if a
specific ACE is not applied to the hardware due to hardware limitations. IPv6-based ACL screens in
Figure 4-10-9
&
Figure 4-10-10
appear.
