183
 Query Interval (sec.) Display the current query interval.
 Query Max Response
Interval (sec.)
Display the current query max response interval.
 Last Member Query
conut
Display the current last member query count.
 Last Member Query
Interval (sec)
Display the current last member query interval.
 Immediate Leave Display the current immediate leave.

Modify
Click to edit parameter.
4.7.4.2 MLD Static Group
The MLD Static Group configuration screens in Figure 4-7-24 & Figure 4-7-25 appear.
Figure 4-7-24 Add MLD Static Group Page Screenshot
The page includes the following fields:
Object Description
 VLAN ID Select VLAN ID for this drop down list.
 Group IP Address The IP address for a specific multicast service
 Member Ports Select port number for this drop down list.
Buttons
: Click to add IGMP router port entry.
